    ES165D-100 Multifunctional Automatic Stacking Yaskawa Robot Arm Extension 3010mm

    Ask Lasest Price
    Brand Name : YASKAWA Robots
    Model Number : ES165D-100
    Payment Terms : D/A, L/C, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000 sets
    Delivery Time : 3-7work day
    • Product Details
    • Company Profile

    ES165D-100 Multifunctional Automatic Stacking Yaskawa Robot Arm Extension 3010mm

    Yaskawa Robot ES165D-100 Multifunctional Fully Automatic Stacking Robot Arm Extension 3010mm Load 100kg


    TypeES165D-100
    Maximum reach3010 mm
    Rated payload100 kg
    StructureVerticial Joint Arm
    BrakesAll axes
    Number of axes6
    Mounting positionFloor, ceiling
    Positioning repeatability±0.2mm
    ControllerDX100
    Weight (excluding controller), approx1120 kg
    Temperature [º C]0 to +45
    Humidity [%]20 – 80
    Maximum
    MotionRange
    S-Axis (Turning/Sweep)±180°
    L-Axis (Lower Arm)+76°/-60°
    U-Axis (Upper Arm)+230°/-142.5°
    R-Axis (Wrist Roll)±360°
    B-Axis (Bend/Pitch/Yaw)±130°
    T-Axis (Wrist Twist)±360°
    Maximum
    Speed
    S-Axis110°/S
    L-Axis110°/S
    U-Axis110°/S
    R-Axis175°/S
    B-Axis150°/S
    T-Axis240°/S

    The Motoman ES165D-100 is an extended reach high payload industrial robot used in material handling, press tending and machine tending applications. This used industrial robot is the successor to the Yaskawa Motoman ES165N-100. This Yaskawa robot uses the advanced Motoman DX100 controller. This used Yaskawa robot is similar in payload and reach to the FANUC R-2000ib 125L, ABB IRB 6640-130 and the KUKA KR90. The ES165D-100 is a floor mounted robot due to its mechanical mass. The Yaskawa ES 165D offers high accurancy and a large work envelope. A used Motoman ES-165D-100 can be integrated to perform deburring and polishing applications .

    ES165D-100 Multifunctional Automatic Stacking Yaskawa Robot Arm Extension 3010mm

    ES165D-100 Multifunctional Automatic Stacking Yaskawa Robot Arm Extension 3010mm

    ES165D-100 Multifunctional Automatic Stacking Yaskawa Robot Arm Extension 3010mm

    FQA


    Q:Who are we?


    A:Pengju Robot Co., Ltd. was established in 2011 and is an intelligent equipment company specializing in imported robot trade, automation project integration, mechanical equipment leasing, sales and repair of robots and robot accessories, robot maintenance, and robot technology training.
    The company has established large-scale sales service centers and technology application centers in Shenzhen, Chongqing, Xiong'an New Area, and Changsha. The company has reserved a group of professional technical engineers, who can provide professional and timely services and complete robot application solutions to support customers' demand for automated production lines to improve production efficiency. The company has always adhered to the corporate tenet of "professionalism is the foundation, service is the guarantee, and quality is the reputation", established a corporate image of "professionalism, professionalism, integrity, and progress", and wholeheartedly provides better products and services for the vast number of users.
    Our goal is to enable customers to truly use robots well


    Q:What brand of robot can you buy from us?


    A:We have Kuka robots, Yaskawa robots, Fanuc robots, ABB robots, and Nazhi robots


    Q:Are they all in stock?


    A:Yes, the company has around 1000 units in stock


    Q:Do you recycle robots?


    A:Recycling, if you have a robot that needs to be recycled, please contact us
